SAP ABAP MCP Server (ADT and JSON RPC)

An MCP server that gives an AI agent full read/write access to an

SAP ABAP system through ADT (ABAP Development Tools), authenticated with **SPNEGO/Kerberos single

sign-on, an X.509 client certificate or an OAuth 2.0 bearer token** — no password anywhere in

the configuration. User and password is still available as fallback but not recommended!

It wraps `abap-adt-api` and adds one thing ADT itself

cannot do: calling RFC-enabled function modules, over the SAP Gateway JSON-RPC 2.0 service.

128 tools — object CRUD, source editing, locks, transports, activation, syntax checks, code

completion, ABAP Unit, ATC, DDIC, abapGit, refactoring, traces, the debugger, and RFC calls.

How many a client actually sees is smaller, twice over. Profiles (`ABAP_MCP_PROFILE`) trade surface

for context: `core` lists 9 tools where `all` lists 129, which is ~2,700 tokens against ~17,800 on

every turn for a client that cannot fetch tool schemas on demand. And the server **asks the system what

it supports** before listing anything, so a release without the abapGit plugin is never offered the 10

tools that would answer 400. On DEV that leaves 116.

> This is the SSO fork of `mcp-abap-abap-adt-api`

> by mario-andreschak. The main differences: Kerberos SSO instead of Basic Auth, the JSON-RPC/RFC

> tools, a router derived from the tool definitions, and a documented tool reference.

Documentation

Features

• Two password-less logon modes — SPNEGO/Kerberos with the logged-on Windows user's ticket, or an

X.509 client certificate for a service or technical user that has no Kerberos identity. No SAP

password is stored or sent either way, and both self-heal when the session expires.

• Streamable HTTP transport, for a team sharing one container — set `ABAP_MCP_TRANSPORT=http` and

each connecting MCP client authenticates with its own SAP OAuth 2.0 bearer token, so every session

gets its own SAP logon rather than everyone sharing one technical user. stdio remains the default

for a single, locally-started client. See §12

and Running over HTTP below.

• Read any object by name — `readAbapObject` resolves a name to its source in one call; no ADT URL

to discover or hand-craft.

• Describe a table — `describeAbapTable` returns fields, DDIC types, key flags and check tables.
• Object management — search, read, create, modify, delete and activate ABAP objects.
• Survey a naming convention — `searchPackages` finds packages by pattern (`["ZPP_*","Z_PP*"]`)

and expands each into its objects grouped by type, in one call.

• Source workflow — lock → edit → syntax check → activate → unlock, with transport handling.
• Code intelligence — completion, definitions, usage references, ABAP Doc, pretty printer, ATC,

ABAP Unit, refactoring (rename, extract method).

• Call RFC function modules — `callFunctionViaJsonRpc` executes an RFC-enabled function module and

validates the request against its real signature, read from the system.

• Batch RFC calls in one LUW — `callFunctionsViaJsonRpc` sends several function modules in a single

request, which is what lets an update BAPI and its `BAPI_TRANSACTION_COMMIT` share one LUW.

• Data access — `tableContents` and ad-hoc `runQuery` SELECTs.
• See the running system — `listLoggedOnUsers` answers "who is logged on" from `TH_USER_LIST`, the

data behind `SM04`; `readProfileParameters` reads RZ11 values in one round trip; and

`checkLogonConfiguration` says which authentication the system actually accepts.

• Bundled agent skills — 54 skills under `skills/`, for ABAP (Clean ABAP, RAP, CDS, ATC,

abapGit…) and general engineering (TDD, code review, diagnosing bugs), served as resources and via

`readSkill`.

• Self-documenting — the guides below are served by the server itself, as MCP resources

(`abap-adt://guides/…`) and through the `readServerGuide` tool, so an agent can look up a workflow or

an argument mid-task without leaving the session.

Prerequisites

• An SAP ABAP system reachable over ADT. `/sap/bc/adt` must be active in `SICF`. For the RFC tools,

`/sap/gw/jsonrpc` must be active as well (`SAP_GWFND`), and your user needs `S_RFC` for the function

groups you call.

• A way to log on without a password, one of:
  • A working Kerberos login — the SAP system must accept SPNEGO and you must hold a valid ticket

(`klist`). This is the default, and it needs Windows as shipped: the bootstrap shells out to

`C:\Windows\System32\curl.exe --negotiate`, which needs curl's Schannel/SSPI backend. On other

platforms point `SSO_CURL_PATH` at a curl built with GSS-API support.

Needs neither curl nor Windows. SAP has to be set up for it: the ICM port must request a

certificate (`VCLIENT` in `icm/server_port_`, which overrides `icm/HTTPS/verify_client`), the

issuing CA trusted in `STRUST`, and a `CERTRULE` mapping to the user. Full setup — including how

to check those from this server — in `docs/Authentication.md`.

no ICM to configure, or for an on-premise system that publishes ADT through `SOAUTH2`. A BTP

service key is already one of these. See §11.

• Node.js (LTS) and npm — verify with `node -v` and `npm -v`.

Installation

git clone --recurse-submodules https://github.com/Ciltress/sap-abap-mcp.git
cd sap-abap-mcp
npm install
npm run build

> `--recurse-submodules` matters: the general engineering skills live in a submodule, and without it

> that directory is empty and the server offers 35 fewer skills. Already cloned? Run

> `git submodule update --init --recursive`.

> The `npx mcp-abap-abap-adt-api` package on npm is the upstream server and does _not_ include the

> SSO bootstrap or the RFC tools. Build this repository from source instead.

Configure

Copy `.env.example` to `.env` and fill in your system:

SAP_URL=https://your-sap-server.example.com:44301
SAP_USER=YOUR_SAP_USER
SAP_CLIENT=100
SAP_LANGUAGE=EN

`SAP_URL` and `SAP_USER` are required; `SAP_CLIENT` and `SAP_LANGUAGE` are optional but recommended.

Three of the four logon modes need no `SAP_PASSWORD` at all.

Never commit `.env`; it is already in `.gitignore`.

Sizing the server for its client

The three `ABAP_MCP_*` variables exist for one reason: **a client that cannot fetch tool schemas on

demand pays for the entire tool list on every single turn.** Claude Code defers schemas and should stay

on the default; an 8B model with a 128k window is spending a sixth of its context before the

conversation starts, and that is where "the same prompt works half the time" comes from.

`ABAP_MCP_PROFILE` — unset means `all`, so an existing setup is unchanged.

Counts include `healthcheck`, which sits outside every profile because it is the tool that answers

"which profile am I running?".

A profile is not a convenience filter. A tool outside the active profile is not listed _and_ not

routed, so it cannot be called — which is what makes `analyst` a guarantee that nothing edits source

rather than a smaller menu. Out-of-profile calls get an error that says so, instead of "unknown tool",

so there is no point retrying. An unrecognised profile name stops the server at startup rather than

falling back to `all` — silently serving 129 tools to something that asked for 9 is the exact failure

profiles exist to prevent.

`core` is small because one tool, `editAbapSource`, _is_ the write cycle: lock, write, activate, unlock,

releasing the lock even when a step fails. The four separate steps stay in `dev` and `all`.

`ABAP_MCP_MAX_RESPONSE_BYTES` — the tool list is a fixed cost a profile can shrink; an answer is

unbounded. On `core` the whole tool list is ~11KB while one `adtDiscovery` is ~42KB. Unset follows the

profile (`core` 24,000 bytes, `analyst` 32,000, `dev` 48,000, `all` no ceiling); `0` removes it.

An over-budget answer is withheld and replaced by valid JSON — `status:"truncated"`, the original

`bytes`, the `budget`, a 2,000-byte `preview` and a `nextStep` — never by a cut-off fragment, which

would not parse and would just invite the identical retry.

`ABAP_MCP_GATE` — before listing anything the server asks the system what it supports, and withholds

the tools whose ADT collections are absent. On DEV that is the 10 abapGit tools and the 3

service-binding tools, which would otherwise answer HTTP 400. It costs one discovery round trip per

process, can only ever shorten the list, and any failure leaves every tool listed. `ABAP_MCP_GATE=off`

skips it.

`healthcheck` reports all three: the active profile, `responseBudgetBytes`, and anything withheld.

A certificate instead of Kerberos

For a service or technical user, add a certificate — that alone switches the mode:

SAP_USER=CLAUDEAGENT                                 # the user CERTRULE maps the certificate to
SAP_CERT_FILE=C:\Users\svc_agent\SNC\sec\claudeagent.p12
SAP_CERT_PASSPHRASE=

> This is mutual TLS, not SNC — ADT is HTTPS. A certificate that already works for RFC/SNC can be

> reused and its `CERTRULE` mapping carries over, but the `SNC0` ACL plays no part and the ICM needs

> `icm/HTTPS/verify_client`. `docs/Authentication.md` covers the differences,

> the `sapgenpse export_p12` / OpenSSL 3 trap, and how to read a rejected certificate.

An OAuth 2.0 client, for BTP and for SOAUTH2

For an SAP BTP ABAP environment, or an on-premise system that publishes ADT behind an authorisation

server. Setting the client id switches the mode:

SAP_OAUTH_TOKEN_URL=https://your-tenant.authentication.eu10.hana.ondemand.com/oauth/token
SAP_OAUTH_CLIENT_ID=sb-abap-agent!t1234              # 'clientid' in a BTP service key
SAP_OAUTH_CLIENT_SECRET=

On-premise the endpoint is on the SAP host itself — `https://:/sap/bc/sec/oauth2/token` —

and the client is the one registered in `SOAUTH2`.

> The token logs on once. After that the SAP session cookie carries every request, as in the

> other modes — so a token that expires in five minutes is not a problem. Note that an OAuth 2.0

> client on AS ABAP _is_ a user in `SU01`: a wrong `SAP_OAUTH_CLIENT_SECRET` counts against

> `login/fails_to_user_lock` like a password, so a refused token request is never retried. The

> authorization-code flow is not implemented — it needs a browser, which a server started over stdio

> has no way to open; complete it once by hand and pass the refresh token in.

> `docs/Authentication.md` §11 has the detail, including which failures are

> latched and why.

A password, when there is nothing else

For a system with neither Kerberos nor certificates — a sandbox, a trial, anything off the domain:

SAP_USER=CLAUDEAGENT
SAP_PASSWORD=

> The last resort, and not interchangeable with the other two. A missing ticket or an unmapped

> certificate is simply refused; a _wrong password_ counts against `login/fails_to_user_lock` and

> locks that user for every consumer of it, not just this server. The implementation refuses to retry

> a rejected password for that reason — one failed logon, latched, however many tools are called.

> Prefer a certificate for anything unattended. `docs/Authentication.md` §10

> has the detail.

Register with an MCP client

Point the client at the built entry point with absolute paths:

{
  "mcpServers": {
    "sap-abap-dev-100": {
      "command": "node",
      "args": ["C:/path/to/sap-abap-mcp/dist/index.js"],
      "env": {
        "SAP_URL": "https://your-sap-server.example.com:44301",
        "SAP_USER": "YOUR_SAP_USER",
        "SAP_SYSTEM_ID": "DEV",
        "SAP_CLIENT": "100",
        "SAP_LANGUAGE": "EN"
      }
    }
  }
}

The client's `env` block wins over `.env`. Run `npm run start` to launch the server by hand, or

`npm run dev` to drive it through the MCP Inspector.

For a client that carries every tool schema on every turn, add a profile to that same block:

"env": { "…": "…", "ABAP_MCP_PROFILE": "core" }

In Docker

By default the server speaks MCP over stdio, so there is no port to publish — the client starts

the container and talks to it over stdin/stdout. This section covers that default; for a container

several team members connect to over the network instead, see Running over HTTP

below.

docker build -t abap-adt-mcp .

{
  "mcpServers": {
    "sap-abap-dev-100": {
      "command": "docker",
      "args": [
        "run",
        "-i",
        "--rm",
        "--env-file",
        "C:/path/to/.env",
        "abap-adt-mcp"
      ]
    }
  }
}

All four logon modes work in here, but a credential is something the container has to be _given_,

and `--env-file` is not dotenv — Docker strips no quotes, reads no `export`, and drops no trailing

`# comment`, so a value dotenv would have cleaned up arrives verbatim. Windows paths in `.env` have

to be replaced by the mounted ones. Kerberos is the mode that needs the most from the container and

OAuth the least: a token is fetched over the network, so nothing has to be mounted at all.

Certificate mode — mount the key material read-only, and the CA that signs _SAP's_ certificate

with it:

docker run -i --rm --env-file .env \
  -v /host/certs:/certs:ro \
  -e SAP_CERT_FILE=/certs/agent.p12 \
  -e SAP_CA_FILE=/certs/corporate-root.pem \
  abap-adt-mcp

Kerberos mode — the image carries a curl built against GSS-API and `kinit`, so what is left is a

realm and a credential:

docker run -i --rm --env-file .env \
  -v /etc/krb5.conf:/etc/krb5.conf:ro \
  -v /host/agent.keytab:/krb5/agent.keytab:ro \
  -e SAP_KRB_KEYTAB=/krb5/agent.keytab \
  -e SAP_KRB_PRINCIPAL=SVC_AGENT@CORP.EXAMPLE.COM \
  abap-adt-mcp

OAuth 2.0 mode — nothing to mount; the credential is fetched:

docker run -i --rm --env-file .env \
  -e SAP_OAUTH_TOKEN_URL=https://your-tenant.authentication.eu10.hana.ondemand.com/oauth/token \
  -e SAP_OAUTH_CLIENT_ID='sb-abap-agent!t1234' \
  -e SAP_OAUTH_CLIENT_SECRET= \
  abap-adt-mcp

Password mode — Last resort!

docker run -i --rm --env-file .env \
  -e SAP_USER=YourUser \
  -e SAP_PASSWORD=YourPassword \
  abap-adt-mcp

Three things to know before you reach for it:

• A keytab, not your own ticket. A container cannot borrow the session's credential the way an

interactive logon does. On a Linux host you can mount the ticket cache you already have

(`-v /tmp/krb5cc_1000:/krb5/ccache:ro -e KRB5CCNAME=FILE:/krb5/ccache`), but it expires with the

host's. From a Windows host neither works: the TGT lives in the LSA cache and cannot be written

to a file — use certificate mode, which needs none of this. The keytab is the only credential that

runs unattended, and the only one that outlives the ticket lifetime.

• Verify SAP's certificate, or know that you are not. The image trusts only the public CA bundle,

so an internal CA the host trusts is unknown in here and the handshake fails with

`UNABLE_TO_GET_ISSUER_CERT_LOCALLY`. Mount the root CA and point `SAP_CA_FILE` at it. Carrying a

desktop `.env` in wholesale hides this instead: `NODE_TLS_REJECT_UNAUTHORIZED=0` is a development

setting and has no business in a deployed image.

• Build from a `--recurse-submodules` clone. `skills/Development` is a submodule; without it the

image ships 35 fewer skills.

The image is Debian rather than Alpine for one reason: Alpine's curl is built without GSS-API, and

such a curl does not fail — it simply never sends a token, and SAP answers the same 401 an expired

ticket produces. What is missing is named at startup, on stderr, before a session is attempted. To ask

the container what credential it ended up with, give it a command instead of the server:

docker run --rm --env-file .env -v /host/agent.keytab:/krb5/agent.keytab:ro \
  -e SAP_KRB_KEYTAB=/krb5/agent.keytab abap-adt-mcp klist

`docs/`, `skills/` and `AGENTS.md` are copied into the image on purpose — the server reads them at

runtime to serve `readServerGuide`, `readSkill` and the `abap-adt://` resources.

`docs/Authentication.md` §7 has the full container setup, mode by mode.

Running over HTTP

Everything above starts one server for one client over stdio. Set `ABAP_MCP_TRANSPORT=http` instead to

run a long-lived container that a whole team connects to over the network, using the SDK's Streamable

HTTP transport at `/mcp`.

HTTP mode changes _who logs on_, not what a session can do once logged on: none of the four modes

above — `SAP_AUTH_MODE`, `SAP_CERT_FILE`, `SAP_OAUTH_CLIENT_ID`, `SAP_PASSWORD` — apply here, because

there is no single shared logon to configure. Instead, **every MCP client authenticates with its own

SAP OAuth 2.0 bearer token**: it sends `Authorization: Bearer ` on `initialize`, and that token

becomes that session's own SAP identity — its own ADT logon, its own locks, its own audit trail. Two

team members connecting at once get two independent sessions, never one shared technical user.

docker build -t abap-adt-mcp .
docker run --rm -p 3000:3000 \
  -e SAP_URL=https://your-sap-server.example.com:44301 \
  -e SAP_USER=CLAUDEAGENT \
  -e SAP_CLIENT=100 \
  -e ABAP_MCP_TRANSPORT=http \
  abap-adt-mcp

`SAP_USER` is still required (every non-password mode needs a placeholder username to construct the

ADT client) but is never transmitted and has no bearing on who a given session actually is — SAP

decides that from each session's own token, same as in §11.

Register a client the same way as any remote Streamable HTTP MCP server, pointing it at `/mcp` and

supplying that user's own SAP OAuth token:

{
  "mcpServers": {
    "sap-abap-dev-100": {
      "url": "http://your-host:3000/mcp",
      "headers": { "Authorization": "Bearer " }
    }
  }
}

A request with no credential is rejected with `401` before any SAP traffic; a token SAP itself refuses

is also `401`, with SAP's own message. There is no separate shared secret to configure for the

transport itself — the SAP token _is_ the access control.

A client that would rather not be disconnected each time its access token expires can send its own

refresh token as `X-SAP-Refresh-Token` instead, and the session renews itself on the `refresh_token`

grant. That needs `SAP_OAUTH_TOKEN_URL` and `SAP_OAUTH_CLIENT_ID` on the container — the client

registration a refresh token is redeemed against is the deployment's, while the refresh token, and

therefore the SAP identity, stays the caller's.

Browser origins are refused unless `ABAP_MCP_HTTP_ALLOWED_ORIGINS` names them: that is the

DNS-rebinding guard the MCP spec asks the server to apply itself, since a rebinding request never

passes through the proxy in front. Allow-listed origins get the matching CORS headers. Clients that

send no `Origin` — every MCP client that is not a web page — are unaffected.

The container's `docker-entrypoint.sh` skips its Kerberos setup automatically when

`ABAP_MCP_TRANSPORT=http` is set, since `resolveAuthMode()`'s pick describes nothing real once every

session logs on with its own token. TLS termination is left to whatever sits in front of the container

(a reverse proxy or ingress), the same as for any other internal HTTP service. Full detail, including

the OAuth grant mechanics this reduces to, is in

`docs/Authentication.md` §12.

More than one system

A server is bound to one system and one client for its whole life — neither can be switched at

runtime. So register one entry per system/client and give each its `SAP_SYSTEM_ID`:

"sap-abap-dev-100": { "env": { "SAP_SYSTEM_ID": "DEV", "SAP_CLIENT": "100", "…": "…" } },
"sap-abap-dev-200": { "env": { "SAP_SYSTEM_ID": "DEV", "SAP_CLIENT": "200", "…": "…" } },
"sap-abap-q01-100": { "env": { "SAP_SYSTEM_ID": "Q01", "SAP_CLIENT": "100", "…": "…" } }

Each server then announces itself in the MCP `instructions` it returns at connect time:

> This server is bound to SAP system DEV, client 100 (https://…:44301).

> It cannot switch system or client at runtime — both are fixed by the environment it was started

> with. If a request names a different system or client, use the MCP server configured for that one;

> if none is registered, say so rather than acting here.

That is what lets an agent route "please check this in DEV client 200" to the right server without

calling anything. `healthcheck` reports the same identity for a server that needs asking directly.

The declaration is checked. SAP names the system and client in the session cookie it sets at

logon (`SAP_SESSIONID_DEV_100`), so the server knows what it is really connected to. If that

disagrees with `SAP_SYSTEM_ID` — a copy-pasted entry pointing at the wrong host, say — `healthcheck`

carries a `WARNING` and it is logged loudly at startup. Worth watching for, because every tool goes

on working perfectly; just on the wrong system.

Quick tour

Read any object by name — no URL discovery needed:

{"tool":"readAbapObject","args":{"objectName":"ZCL_MY_CLASS"}}
{"tool":"describeAbapTable","args":{"tableName":"T000"}}

Survey a whole naming convention — patterns are normalised for you, so `zpp_lab` becomes `ZPP_LAB*`:

{ "tool": "searchPackages", "args": { "patterns": ["ZPP_*", "Z_PP*"] } }
// -> each package with its objects grouped by type, sub-packages, and a `truncated` flag

Call a function module — the signature is read first and the request validated against it:

{"tool":"readAbapFunctionModule","args":{"functionModuleName":"STFC_CONNECTION"}}
{"tool":"callFunctionViaJsonRpc","args":{"functionModuleName":"STFC_CONNECTION",
                                         "inputParameters":{"REQUTEXT":"hello"}}}

A BAPI and its commit must travel in one batch, or the commit lands in its own LUW and the BAPI's

changes are lost:

{
  "tool": "callFunctionsViaJsonRpc",
  "args": {
    "calls": [
      {
        "functionModuleName": "BAPI_USER_LOCK",
        "inputParameters": { "USERNAME": "DEVUSER" },
      },
      {
        "functionModuleName": "BAPI_TRANSACTION_COMMIT",
        "inputParameters": { "WAIT": "X" },
      },
    ],
  },
}

The full write cycle (lock → modify → check → activate → unlock), the debugger, ATC and every other

workflow are in `docs/MCP-Tools.md` §4.

Working with ABAP objects

Three tools cover most of what you need, and each takes a name rather than an ADT URL:

{"tool":"readAbapObject",   "args":{"objectName":"ZCL_MY_CLASS"}}
{"tool":"describeAbapTable","args":{"tableName":"T000"}}
{"tool":"searchPackages",   "args":{"patterns":["ZPP_*","Z_PP*"]}}

`readAbapObject` returns the metadata _and_ the source in one call. When a name belongs to several

objects — `ZPP_EXT_LABEL_DATA` is both a function group and a function module — it picks the more

specific one and tells you, via `ambiguous:true` and `alternatives`; pass `objectType` to force the

choice. Objects with no source come back with `hasSource:false` and a pointer to the right tool.

`describeAbapTable` gives field names, DDIC types, lengths, key flags, data elements, domains and

check tables — the check table is the foreign-key target, which is the quickest way to see how two

tables join. `objectStructure` returns no fields for a table, and `tableContents` returns rows rather

than a definition, so neither answers "what does this table look like".

Rules worth putting in your client's system prompt

• Prefer the by-name tools. Only fall back to `searchObject` → `objectStructure` → `getObjectSource`

when you need the intermediate results. Never hand-craft a `/sap/bc/adt/...` path.

• Select efficiently. SAP tables are large. Always constrain `SELECT`s with a `WHERE` clause, and

use `SELECT SINGLE` (all key fields known) or `UP TO n ROWS` otherwise.

SELECT vgbel FROM vbrp WHERE vbeln = @lv_vbeln INTO @DATA(lv_vgbel) UP TO 1 ROWS.
  EXIT.
ENDSELECT.

SAP is decoupled from your file system: reading source returns it as a tool result only, and writing a

local file changes nothing in SAP. Local copies are useful for diffing, nothing more.

> Earlier READMEs listed `GetTable`, `GetStructure` and `GetTypeInfo`. Those belong to the separate

> `mcp-abap-adt` project, not to this server.

Development

npm run build          # tsc -> dist/
npm test               # vitest: parser, tool catalogue, JSON-RPC handler (no SAP system needed)
npx tsc --noEmit       # type check only

Tests live in `src/__tests__` and run entirely offline — the JSON-RPC suite exercises

the handler end to end against a fake SAP Gateway node.

Against a real system (needs a Kerberos ticket), the end-to-end check is:

npm run build
node scripts/live-jsonrpc-check.mjs      # add NODE_TLS_REJECT_UNAUTHORIZED=0 for an internal CA

It drives the built server over MCP stdio exactly as a client would, and only calls read-only function

modules.

Adding a tool is a one-file change — see `docs/MCP-Tools.md` §10.

Troubleshooting

More in `docs/MCP-Tools.md` §8.

Contributing

1. Fork the repository

2. `git checkout -b feature/your-feature-name`

3. Make your change, keep `npm test` and `npx tsc --noEmit` green

4. `git commit -m "Add some feature"` and `git push origin feature/your-feature-name`

5. Open a pull request

License

MIT. Upstream project and original author: mario-andreschak.
